Shotgun Rear Custom Fender Short 90 Degree Steel Choppers
Get the ultimate bobbed look with just enough fender to keep it clean and leave the rest exposed.
The Shotgun Rear Fender covers the critical top arc of the wheel while letting the rest of your tire, hub, and drivetrain breathe in the open air – the definitive choice for the stripped-down chopper aesthetic.

Key Features:

Short 90-degree coverage – approximately 21-inch arc exposes maximum tire and drivetrain
Classic “bobbed” look without sacrificing the quality of the clean radius side profile
Compact arc length reduces overall visual mass for a stripped-down, aggressive stance
Hand-spun from 13-gauge U.S. steel with standard 1.75-inch sidewall depth
Ships raw for full control over surface prep, body filler, and paint or powder coat finish

Technical Specifications:

Style: Shotgun (Short / 90-Degree Cut)
Arc Length: Approx. 21 inches (1/4 circle)
Material: 13 Gauge U.S. Steel, TIG Welded
Outer Diameter: 27 inches
Sidewall Depth: 1.75 inches (Standard Radius Profile)
Wheel Compatibility: Optimized for 18-inch motorcycle wheels
Finish: Raw, uncoated hand-spun steel
Origin: Made in the USA

Fitment Notes:

This is a custom fabrication part – not a bolt-on replacement for any specific motorcycle
Requires custom spacers, bungs, or struts for mounting; hardware sold separately
Drilling, welding, and fabrication are required to fit your specific frame width and geometry
Supplied in raw, uncoated spun steel finish; visible spinning lines are normal and expected on hand-spun parts
Apply high-build surfacer or body filler to smooth the surface before painting or powder coating
Optimized for standard 18-inch motorcycle wheels; select fender width by rear tire size

Fender Compatible Tire Width
6 Inch 130mm
7 Inch 160mm
7.75 Inch 170mm
8.5 Inch 180mm
9 Inch 200mm
10.5 Inch 240mm
11 Inch 250mm
11.5 Inch 260mm
12 Inch 280mm
12.5 Inch 280/300mm
13 Inch 300mm
14 Inch 330mm
